產品材質： A.C.F部位采用黃銅鍍鎳（Brass）B.E部位采用丁腈橡膠 制成，D部位采用白色尼龍制成。
螺紋規格：公制（Mefric）德制（PG）、美制（NPT）
工作溫度： 靜態：-40℃~＋110℃，短時可達＋120℃; 動態：-20℃~＋80℃，短時可達＋100℃。
產品顏色：A.C.F部位為黃色，B.E部分為黑色，D部分為白色。
防護等級： 在規定的卡口范圍內，并使用O形密封圈旋緊迫緊頭，防水達IP68。
產品特性：特殊夾緊爪與密封件相扣之設計，配合迫緊頭裝配省時便利，夾緊電纜范圍大，抗拉力特強，可防水、防塵、防鹽、耐酸堿、酒精、油、脂及一般溶劑。
使用方法： TLYBFC電纜防水接頭是電纜的配套產品，接頭可將電纜鎖緊， 另一端可接入設備箱體上，也可以根據選用螺紋接入進 出口為內螺紋的電動設備上。
|
產品型號
|
螺牙規格
|
適應電纜外徑
|
螺紋外徑
|
螺紋長度
|
加長螺紋長度
|
扳手徑
|
|
TLYBFZ-M8
|
M8X1.5
|
2-4
|
8
|
6
|
10
|
13/14
|
|
TLYBFZ-M8FZ
|
M8X1.5
|
2-4.9
|
8
|
6
|
10
|
14/14
|
|
TLYBFZ-M10
|
M10X1.5
|
3-6.5
|
10
|
6
|
10
|
14/14
|
|
TLYBFZ-M10FZ
|
M10X1.5
|
2.5-6.8
|
10
|
6
|
10
|
14/14
|
|
TLYBFZ-M12
|
M12X1.5
|
3-6.5
|
12
|
6
|
10
|
14/14
|
|
TLYBFZ-M12FZ
|
M12X1.5
|
3.5-8.0
|
12
|
6
|
10
|
17/18
|
|
TLYBFZ-M14
|
M14X1.4
|
4-8
|
14
|
6
|
10
|
18/18
|
|
TLYBFZ-M14FZ
|
M14X1.5
|
2.5-6.4
|
14
|
6
|
10
|
16/14
|
|
TLYBFZ-M16
|
M16X1.5
|
4-8
|
16
|
7
|
10
|
18/18
|
|
TLYBFZ-M16FZ
|
M16X1.5
|
5.0-10.0
|
16
|
7
|
10
|
18/20
|
|
TLYBFZ-M18
|
M18X1.5
|
5-10
|
18
|
7
|
10
|
20/20
|
|
TLYBFZ-M20
|
M20X1.5
|
6-12
|
20
|
8
|
10
|
23/22
|
|
TLYBFZ-M20FZ
|
M20X1.5
|
3-8
|
20
|
8
|
10
|
23/18
|
|
TLYBFZ-M20KT
|
M20X1.5
|
5-10
|
20
|
8
|
10
|
23/20
|
|
TLYBFZ-M20WB
|
M20X1.5
|
9-13.8
|
20
|
8
|
10
|
23/24
|
|
TLYBFZ-M22
|
M22X1.5
|
10-14
|
22
|
8
|
10
|
24/24
|
|
TLYBFZ-M24
|
M24X1.5
|
10-14
|
24
|
8
|
10
|
27/24
|
|
TLYBFZ-M25
|
M25X1.5
|
10-16
|
25
|
8
|
12
|
28/28
|
|
TLYBFZ-M25FZ
|
M25X1.5
|
13-18
|
25
|
8
|
12
|
30/30
|
|
TLYBFZ-M27
|
M27X1.5(2)
|
13-18
|
27
|
8
|
12
|
30/30
|
|
TLYBFZ-M28
|
M28X1.5(2)
|
13-18
|
28
|
8
|
12
|
30/30
|
|
TLYBFZ-M30
|
M30X1.5(2)
|
13-18
|
30
|
8
|
12
|
32/32
|
|
TLYBFZ-M30FZ
|
M30X1.5(2)
|
8-12
|
30
|
8
|
12
|
32/32
|
|
TLYBFZ-M30KT
|
M30X1.5(2)
|
14-20
|
30
|
8
|
12
|
32/32
|
|
TLYBFZ-M32
|
M32X1.5(2)
|
15-22
|
32
|
9
|
12
|
36/35
|
|
TLYBFZ-M33
|
M33X1.5(2)
|
15-22
|
33
|
9
|
12
|
36/36
|
|
TLYBFZ-M36
|
M36X1.5(2)
|
18-25
|
36
|
9
|
12
|
40/40
|
|
TLYBFZ-M37
|
M37X1.5(2)
|
18-25
|
37
|
9
|
12
|
40/40
|
|
TLYBFZ-M40
|
M40X1.5(2)
|
18-25
|
40
|
9
|
15
|
42/42
|
|
TLYBFZ-M40FZ
|
M40X1.5(2)
|
22-30
|
40
|
9
|
15
|
42/42
|
|
TLYBFZ-M42
|
M42X1.5(2)
|
22-30
|
42
|
9
|
15
|
42/42
|
|
TLYBFZ-M47
|
M47X1.5(2)
|
25-33
|
47
|
9
|
15
|
52/52
|
|
TLYBFZ-M48
|
M48X1.5(2)
|
25-33
|
47.7
|
9
|
15
|
52/52
|
|
TLYBFZ-M50
|
M50X1.5(2)
|
32-38
|
49.7
|
9
|
15
|
54/54
|
|
TLYBFZ-M54
|
M54X1.5(2)
|
32-38
|
53.6
|
9
|
15
|
54/54
|
|
TLYBFZ-M56
|
M56X1.5(2)
|
30-38
|
55.6
|
9
|
15
|
56/54
|
|
TLYBFZ-M60
|
M60X1.5(2)
|
37-44
|
59.5
|
10
|
15
|
70/63
|
|
TLYBFZ-M63
|
M63X1.5(2)
|
37-44
|
62.6
|
10
|
15
|
70/63
|
|
TLYBFZ-M64
|
M64X1.5(2)
|
37-44
|
63.6
|
10
|
15
|
70/64
|
|
TLYBFZ-M72
|
M72X1.5(2)
|
42-52
|
71.5
|
12
|
23
|
78/78
|
|
TLYBFZ-M75
|
M75X1.5(2)
|
42-55
|
74.5
|
12
|
23
|
82/82
|
|
TLYBFZ-M76
|
M76X1.5(2)
|
42-52
|
75.6
|
12
|
24
|
82/82
|
|
TLYBFZ-M80
|
M80X1.5(2)
|
55-62
|
79.5
|
15
|
24
|
88/88
|
|
TLYBFZ-M88
|
M88X1.5(2)
|
65-70
|
87.5
|
15
|
25
|
98/98
|
|
TLYBFZ-M100
|
M100X1.5(2)
|
78-84
|
99.5
|
15
|
25
|
110/110
|
|
TLYBFZ-M110
|
M110X1.5(2)
|
88-98
|
109.5
|
15
|
25
|
120/120
|
|
TLYBFZ-M125
|
M125X1.5(2)
|
98-108
|
124.5
|
15
|
25
|
135/135
|
|
產品型號
|
螺牙規格
|
適應電纜外徑
|
螺紋外徑
|
螺紋長度
|
加長螺紋長度
|
扳手徑
|
|
TLYBFZ-PG7
|
PG7
|
3-6.5
|
12.5
|
6
|
10
|
14/14
|
|
TLYBFZ-PG9
|
PG9
|
3-6.5
|
15.2
|
7
|
10
|
14/14
|
|
TLYBFZ-PG9
|
PG9
|
4-8
|
15.2
|
7
|
10
|
17/17
|
|
TLYBFZ-PG11
|
PG11
|
5-10
|
18.6
|
7
|
10
|
20/20
|
|
TLYBFZ-PG13.5
|
PG13.5
|
5-10
|
20.4
|
7
|
10
|
22/20
|
|
TLYBFZ-PG13.5
|
PG13.5
|
6-12
|
20.4
|
7
|
10
|
22/22
|
|
TLYBFZ-PG16
|
PG16
|
6-12
|
22.5
|
7
|
10
|
24/22
|
|
TLYBFZ-PG16
|
PG16
|
8-14
|
22.5
|
7
|
10
|
24/24
|
|
TLYBFZ-PG21
|
PG21
|
10-16
|
28.3
|
7
|
12
|
30/27
|
|
TLYBFZ-PG21
|
PG21
|
13-18
|
28.3
|
7
|
12
|
30/30
|
|
TLYBFZ-PG29
|
PG29
|
15-22
|
37
|
8
|
12
|
40/35
|
|
TLYBFZ-PG29
|
PG29
|
18-25
|
37
|
8
|
12
|
40/40
|
|
TLYBFZ-PG36
|
PG36
|
22-32
|
47
|
9
|
15
|
50/50
|
|
TLYBFZ-PG42
|
PG42
|
32-38
|
54
|
9
|
15
|
57/57
|
|
TLYBFZ-PG48
|
PG48
|
37-44
|
59.3
|
10
|
15
|
65/65
|
